37U Series
Single Board, USB 3.1 Industrial Cameras with the Latest Sony Sensors
Equipped with high-performance Sony Pregius and STARVIS sensors, The Imaging Source's cost optimized, 37U Series offers several form factor variants, providing a flexible customization concept for systems engineers and OEMs. 37 Series industrial cameras offer a compact, cost-optimized imaging solution ideal for ideal for high-speed machine vision tasks such as production automation, quality assurance and inspection.
| Product Code | MP | Resolution | FPS | Format | Sensor | Mono/Color | Shutter | Pixel Size | Trigger | I/O | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK 37AUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 " | IMX287 |  |
Global | 6.9 µm | | |
 |
DMK 37BUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 " | IMX287 | |
Global | 6.9 µm | | |
|
DFK 37AUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 " | IMX287 |  |
Global | 6.9 µm | | |
|
DFK 37BUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 " | IMX287 | |
Global | 6.9 µm | | |
|
Subject to change. |
|||||||||||
Features
- CMOS sensors: CMOS (Global), CMOS (Rolling), CMOS STARVIS (Rolling), CMOS Pregius (Global)
- Resolutions: 0.4 MP - 12 MP
- Frame rates: 30 FPS - 539 FPS
- Interface: USB 3.1 Interface
- Trigger and I/O: Multiple variants available. Please see table above for details.
- OEM Cameras: OEM applications and co-branding for customer projects
- Software: The Imaging Source authors and supports device drivers, software development kits (SDKs), end user software, programming samples, extensions, and tools for Microsoft Windows and Linux.
- Warranty: 3-year warranty with continuous support
