Z Series
GigE
Z Series zoom cameras are equipped with the latest global and rolling sensor technology (3.1 MP - 5 MP), providing a wide field of view and perfect image resolution for monitoring and low-light processes. Available in color and monochrome versions, the cameras provide rapid zoom transitions in under 6 seconds, along with software control for autoiris and IR-cut-filter switch.
| Product Code | MP | Resolution | FPS | Format | Sensor | Mono/Color | Shutter | Pixel Size | ||
|---|---|---|---|---|---|---|---|---|---|---|
 |
DMK Z12G445 | 1.2 MP | 1,280×960 | 30 | 1/3 " | ICX445ALA |  |
Global | 3.75 µm | EoL** |
|
DMK Z12GX236 | 2.3 MP | 1,920×1,200 | 41 | 1/2.8 " | IMX236LLJ | |
Rolling | 2.8 µm | |
 |
DMK 39GX265-Z20 | 3.1 MP | 2,048×1,536 | 36 | 1/1.8 " | IMX265 | |
Global | 3.45 µm | |
|
DMK 39GX548-Z20 | 5 MP | 2,448×2,048 | 24 | 1/1.8 " | IMX548 | |
Global | 2.74 µm | |
|
DMK 39GR0522-Z12 | 5 MP | 2,592×1,944 | 22 | 1/2.5 " | AR0522 | |
Rolling | 2.2 µm | New |
|
DMK Z12GP031 | 5 MP | 2,592×1,944 | 15 | 1/2.5 " | MT9P031 | |
Rolling | 2.2 µm | EoL** |
 |
DMK Z30GP031 | 5 MP | 2,592×1,944 | 15 | 1/2.5 " | MT9P031 | |
Rolling | 2.2 µm | EoL** |
|
DFK 39GX265-Z20 | 3.1 MP | 2,048×1,536 | 36 | 1/1.8 " | IMX265 |  |
Global | 3.45 µm | |
|
DFK 39GX548-Z20 | 5 MP | 2,448×2,048 | 24 | 1/1.8 " | IMX548 | |
Global | 2.74 µm | |
|
DFK 39GR0522-Z12 | 5 MP | 2,592×1,944 | 22 | 1/2.5 " | AR0522 | |
Rolling | 2.2 µm | New |
|
DFK Z30GP031 | 5 MP | 2,592×1,944 | 15 | 1/2.5 " | MT9P031 | |
Rolling | 2.2 µm | EoL** |
|
** End-of-life product. Limited stock available. Subject to change. |
||||||||||
Features
- CMOS sensors: CMOS (Rolling), CMOS Pregius (Global), CMOS Pregius S (Global), CCD (Global), CMOS Exmor (Rolling)
- Resolutions: 1.2 MP - 5 MP
- Frame rates: 15 FPS - 41 FPS
- Interface: GigE Interface (RJ45)
- Trigger and I/O: Yes
- OEM Cameras: OEM applications and co-branding for customer projects
- Software: The Imaging Source authors and supports device drivers, software development kits (SDKs), end user software, programming samples, extensions, and tools by tiscamera (NVIDIA) and libcamera (NXP) on Linux ARM.
- Warranty: 3-year warranty with continuous support
