| 特性概要 | |
| 动态范围 | 8 bit |
| 视频格式 @ 帧率 (最大) | 1,280×960 (1.2 MP) Y800 @ 25 fps 1,280×960 (1.2 MP) RGB24 @ 25 fps 1,280×960 (1.2 MP) RGB32 @ 25 fps |
| 接口 (光学) | |
| 红外截止滤光片 | |
| 传感器类型 | CMOS |
| 传感器规格 | onsemi AR0134 |
| 快门 | 全局 |
| 规格 | 1/3 inch |
| 像素 | 水平: 3.75 µm, 垂直: 3.75 µm |
| 镜头接口 | C/CS |
| 接口 (电子) | |
| 接口 | USB 2.0 (向前兼容), 乙太网路供电 |
| 供应电压 | 4.5 VDC 至 5.5 VDC |
| 消耗电流 | 大约 250 mA @ 5 VDC |
| 自动光圈控制 | |
| 触发器 | |
| 输入/输出 | |
| 接口 (机械) | |
| 尺寸 | 高: 36 mm, 宽: 36 mm, 长: 25 mm |
| 重量 | 70 g |
| 调整 | |
| 快门 | 1/10,000 s 至 30 s |
| 增益 | 0 dB 至 18 dB |
| 白平衡 | -6 dB 至 6 dB |
| 环境 | |
| 温度 (作业) | -5 °C 至 45 °C |
| 温度 (储存) | -20 °C 至 60 °C |
| 湿度 (作业) | 20 % 至 80 % (非冷凝) |
| 湿度 (储存) | 20 % 至 95 % (非冷凝) |
| 依实际情形调整更动 | |
 |
Industrial Cameras: Spectral Sensitivity | | 1.30 | 11月 2017 |
 |
Industrial Cameras: USB CMOS - 22, 42 and 72 Series - Pico Blade USB | | 1.6 | 7月 2022 |
 |
DFK 42AUC03 技术手册 | | 1.1 | 2月 2023 |
 |
The Imaging Source Catalog | 新的 | 2010.07 | 10月 2024 |
 |
Datasheet for onsemi AR0134 CMOS Sensor | | 1.1 | 8月 2015 |
 |
